AMP CONNECT® SPARX® Fiber Cassatte 12 MTP to 6 LC Duplex Multi-Mode OM3
| Product Classification | |
|---|---|
| Regional Availability | Asia | Europe | Middle East | Africa |
| Portfolio | LEXF® |
| Product Type | Fiber patch panel |
| Product Series | LD1 |
| General Specifications | |
| Mounting Type | Rack 19-in | Rack 23-in | Cabinet-mount |
| Color | Black |
| Panel Specifications | |
| Total Fibers Capacity | 144F |
| Number of Panels | Cassettes Available | 6. |
| Front Interface | Unloaded |
| Cable entry type | External and Internal strain-relief bracket |
| Fiber Shelf Movement | Sliding |
| Material Specifications | |
| Housing Material | Powder-coated metal and polycarbonate tray |
| Mechanical Specifications | |
| Rack Unit Hight | 2U |
| Environmental Specifications | |
| Temperature range, operation | -40 °C to 70 °C (-40 °F to 158 °F ) |
| Regulatory Compliance/Certifications | |
| ROHS | Compliant. |
| CHINA-ROHS | Below maximum concentration value |
| Safety Standard | CSA 22.2 | UL 1863 |
| Temperature range, Approvals and Listings | Meets ANSI/TIA/EIA-568A and 606 | Tested in accordance with Telecordia GR-63-CORE | UL1863 - Communication Circuit Accessories |
| UK-ROHS | Compliant |
