| Product Classification | |
|---|---|
| Regional Availability | Asia | Europe | Middle East | Africa |
| Portfolio | THUNDER X10® |
| Product Type | Modular jack |
| Product Series | FLEX |
| General Specifications | |
| ANSI/TIA Category | Cat 6A |
| Cable Type | Shielded |
| Conductor Type | Solid | Stranded |
| Transmission Standards | ANSI/TIA-568.2-D | ISO/IEC 11801 Class EA |
| Wiring | T568A | T568B |
| Compatible Conductor Gauge, stranded | 26–24 |
| Termination Type | Tool Less |
| Outlet Type | Standard |
| Integrated Dust Cover Type | NO |
| Compatible Conductor Gauge, solid | 24–22 AWG |
| Color | Blue |
| Material Specifications | |
| Contact Plating Material | Gold |
| Material Type | Polycarbonate | Zamak |
| Termination Contact Plating | Tin |
| Electrical Specifications | |
| Insulation Resistance, minimum | 500 MOhm |
| Dielectric Withstand Voltage, RMS, conductive surface | 1500 Vac at 60 Hz |
| Current Rating at Temperature | 1.5 A at 20 °C | 1.5 A at 68 °F |
| Contact Resistance, maximum | 100 mOhm |
| Contact Resistance Variation, maximum | 20 mOhm |
| Environmental Specifications | |
| Operating Temperature | -10 °C to +60 °C (+14 °F to +140 °F) |
| Flammability Rating | UL 94 V-2 |
| Storage Temperature | -40 °C to +70 °C (-40 °F to +158 °F) |
| Safety Standard. | UL |eTL |
| Dimensions | |
| Width | 16.8 |
| Height. | 19.6 |
| Depth. | 42.5 |
| Packing | |
| Packaging quantity | 1PC |
