• Regional Availability

  • Asia | Europe | Middle East | Africa

• Portfolio

  • OFYX®

• Product Type

  • Fiber Indoor/Outdoor cable

• Product Series

  • SM Fiber

• Subunit Type

  • Gel-free

• Flame Rating

  • Flame-retardant | non-corrosive/low-smoke | zero-halogen (FRNC/LSZH) material

• Cable Type

  • Loose Tube

• Construction Type1

  • Dielectric Armour

• Application

  • Aerial |  Direct Buried |  Duct |  General Purpose Horizontal

• Fiber Count

  • 48F

• Number of ripcords

  • 2 ripcords

• Fiber per tube

  • 12F

• Outer jacket colour

  • Black.

• Outer Jacket Material

  • Flame-retardant | non-corrosive/low-smoke | silicon-free | zero-halogen (FRNC/LSZH) material

• REACh Regulation

  • REACh Declaration

• Minimum Bend Radius, operation

  • 74 mm (2.91 in)

• Nominal outer diameter

  • 7.4 mm  (0.29 in )

• Max. tensile strength for installation

  • 1350 N (303.49 lbf)

• Minimum Bend Radius, installation

  • 111 mm (4.37 in)

• Fibre category

  • OS2

• Cable cutoff wavelength

  • 1260 nm

• Fibre name

  • OFYX

• Fibre compliance

  • ITU-T G.652.D/G.657.A1

• Dispersion @ 1550 nm

  • 18 nm

• Dispersion @ 1625 nm

  • 22 nm

• Maximum Attenuation

  • 0.4 dB/km / 0.4 dB/km / 0.3 dB/km

• Wavelengths

  • 1310 nm / 1383 nm / 1550 nm

• Fibre Type

  • Single-mode

• Temperature range, installation

  • -10 °C to 60 °C (14 °F to 140 °F )

• Temperature range, operation

  • -30 °C to 70 °C (-22 °F to 158 °F )

• Temperature range, storage

  • -40 °C to 70 °C (-40 °F to 158 °F ).

• Design and Test Criteria

  • ANSI/ICEA S-104-696 | NFPA 262 (for plenum - riser and general building applications).

• ROHS

  • Free of hazardous substances according to RoHS 2011/65/EU

• Approvals and Listings

  • Flame retardant according to IEC 60332-1-2 (single cable) | IEC 60332-3-24 (bunch of cables) | Low smoke according to IEC 61034 | Non-corrosive according to IEC 60754-2 | Reaction to fire according to EN 50575 and EN 13501-6
