• Regional Availability

  • Asia | Europe | Middle East | Africa

• Portfolio

  • THUNDER X1®

• Product Type

  • Modular jack

• Product Series

  • FLEX

• ANSI/TIA Category

  • Cat 6

• Cable Type

  • Unshielded

• Conductor Type

  • Solid | Stranded

• Transmission Standards

  • ANSI/TIA-568.2-D | ISO/IEC 11801 Class E

• Wiring

  • T568A | T568B

• Compatible Conductor Gauge, stranded

  • 26–24

• Termination Type

  • Punchdowns

• Outlet Type

  • Standard

• Integrated Dust Cover Type

  • NO

• Compatible Conductor Gauge, solid

  • 24–22 AWG

• Color

• Contact Plating Material

  • Gold

• Material Type

  • Polycarbonate

• Termination Contact Plating

  • Tin

• Remote Powering

  • Fully supports the safe delivery of power over LAN cabling described by IEEE 802.3bt Type 4 - complies with the unmating under electrical load requirements prescribed by IEC 60512-99-003

• Insulation Resistance, minimum

  • 500 MOhm

• Dielectric Withstand Voltage, RMS, conductive surface

  • 1500 Vac at 60 Hz

• Current Rating at Temperature

  • 1.5 A at 20 °C | 1.5 A at 68 °F

• Contact Resistance, maximum

  • 100 mOhm

• Contact Resistance Variation, maximum

  • 20 mOhm

• Operating Temperature

  • -10 °C to +60 °C (+14 °F to +140 °F)

• Flammability Rating

  • UL 94 V-1

• Storage Temperature

  • -40 °C to +70 °C (-40 °F to +158 °F)

• Safety Standard.

  • UL |eTL

• Width

  • 16.1

• Height.

  • 20.05

• Depth.

  • 38

• Packaging quantity

  • 1PC
